Execute Entity Actions in One or Two Stages

In the simplest implementation of entity maintenance, the action executes immediately after the user issues the command. This is known as a one-stage execution. However, to reduce the risk of unintentionally executing entity actions that affect the database, you can have Procedure Synthesis generate Action Diagram logic that requires a two-stage execution:

• In the first stage, the user enters a command and the system returns a request for confirmation of the action.
• In the second stage, the user confirms the action and the system executes it.

During confirmation, the screen is protected from input.

You can select one- or two-stage execution individually for the create, update, and delete entity actions when you select an entity maintenance stereotype. Two-stage execution is most commonly used for the delete entity action.

The following example shows the Action Diagram statements that Procedure Synthesis generates for a two-stage deletion:
