Split Application Configuration

The split application configuration is a hybrid of the DBA configuration. The split application configuration has two model levels:

• A Core Model level with the core model that contains the files common to multiple applications. These files are maintained at the core model level and copied to the application models. The core model may have been created from a standards model.
• An Application Model level with multiple application models for application-specific DBA configurations.

The split application configuration provides flexibility with control in environments that need application-specific data models.

You set up a split application configuration as you would set up a DBA configuration:

1. Create the core model.
2. Set up the application models.

If you want to specify a generation library that is different from the generation library at the core level, add the core model generation library to the application level library lists after the application model generation library.
